Ubiquiti NanoSwitch (N-SW)

$0.00

Technical specification:
Dimensions 196.4 x 93.5 x 32.4 mm (7.73 x 3.68 x 1.28″)
Weight 271 g (9.6 oz)
Enclosure Characteristics White Polycarbonate
Total Non-Blocking Line Rate 4 Gbps
Typical Power Consumption 1.5W
Passive PoE Max. Wattage per Port 24V, 2-Pair, 1A per Port (24W)
Total Passive PoE Max. Wattage 24V, 2-Pair, 1A for 3 Ports (24W)
Power Method Passive 24V, 2-Pair PoE In
Power Supply POE-24-24W PoE Adapter (Not Included)
Passive PoE Voltage Range 21.6 – 26.4V
LEDs Speed/Link/Activity (All Ports)
Networking Interfaces (4) 10/100/1000 Mbps RJ45 Ports
PoE Interfaces Passive 24V, 2-Pair PoE In
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -30° to 70° C (-22° to 158° F)
Operating Humidity 5% to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4 Standard
Certifications CE, FCC, IC

Add to wishlist
Compare
Categories: ,
Description

Description

N-SW – Ubiquiti NanoSwitch
NanoSwitch (N-SW) Ubiquiti
The NanoSwitch™ is an unmanaged switch with four Gigabit Ethernet ports. For its total non-blocking line rate, the NanoSwitch supports up to 4 Gbps.

Featuring a durable, weatherproof form factor, the NanoSwitch is ideal for outdoor deployment. For quick installation, the compact NanoSwitch can be easily mounted on a pole or wall.

The NanoSwitch has four PoE ports:
Ports Passive PoE
(1) PoE In 24V, 2-Pair
(3) PoE Passthrough 24V, 2-Pair
